Set-screw coupling TR made of steel bore 20mm without keyway
Set-screw coupling TR made of steel bore 20mm without keyway: Beam Couplings: Industrial & Scientific. Set-screw coupling TR made of steel bore 20mm without keyway: Beam Couplings: Industrial & Scientific. Material: Steel C45, burnished.。These couplings do not allow any shaft displacement 。in axial or radial direction. They should therefore only 。be used with perfectly alligned shafts. 。Bore tolerance: +0,05 mm.。The torques in the table are maximum values for couplings 。with keyway. The calculations based on feather-key connection.。For couplings without keyway: The transmittable torque 。is lower and depends on how far the set screws penetrate the shaft.。Torque max. [Nm]70d [mm]20A [mm]42L [mm]65K [mm]6Bolts DIN 916M6Torque Ms [Nm]7,2Weight [g]518 。 。 。
